Mateu

Bring your own design system

Mateu’s frontend and backend communicate through a simple, documented JSON API. Any frontend that implements this API becomes a valid Mateu renderer.

How it works

Section titled “How it works”

The Mateu backend exposes one sync endpoint per mount. A renderer POSTs the current route and any user action to it, and gets back a UI increment to apply:

POST /{baseUrl}/mateu/v3/components/_/action
Body: { "route": "...", "actionId": "<the load action> | <methodName>", "componentState": { ... } }

The response is a UIIncrementDto carrying commands (navigation, window title, …), messages (toasts/alerts) and fragments (the component tree to render or patch). The same increment shape drives every interaction, so a renderer only ever implements one request/response.

A renderer:

  1. POSTs the route with the load action to get the initial fragments
  2. renders the fragments using its own component library
  3. sends user interactions back as further actions (the method’s actionId + componentState)
  4. applies the response — fragments, commands and messages

See the renderer contract for the authoritative wire spec (exact action ids, component types and the increment schema).

Starting point

Section titled “Starting point”

Clone one of the existing renderer repositories and adapt it to your component library. The Vaadin renderer source is the most complete reference implementation.

When to use this

Section titled “When to use this”
  • You want Mateu UIs to match your company’s proprietary design system
  • You are embedding Mateu in a platform with its own mandatory component library
  • You want to render Mateu UIs in a non-browser environment (native mobile, desktop)
